TDB II Series - Direct Driven Bifurcated Fan

Construction

Belt driven type. Double flanged casing is produced in mild steel or galvanised steel. The impeller with manually adjustable pitch blades is made of PPG, PAG or Aluminium alloy.

Coatings

Zinc rich primer and polyester powder coating or galvanized finishing are available for all mild steel parts.

Thông số kỹ thuật

Quick Facts

Size from 400 to 1400 mm
Capacity up to 140,000 m3/h
Static pressure up to 1000 Pa
Suitable for general ventilation, kitchen exhaust and removal of contaminated air.

Operating Temperature

Normal Ventilation: -20°C to +180°C.

Motor

Totally enclosed Class 'F', with a minimum IP54 protection are fitted as standard. Standard motor up to 2.2kW are supplied with DOL starting, motor 3.0kW and above are with star/delta starting. Motor of other specifications are available upon request.
